Weldy
Foiler ETL, 230V/1700W, 20mm, CN plug
Details perfect for tarpaulins and banners
The intuitive use and automatic start up makes overlap welding tarpaulins and banners easy. The integrated guide roller ensures optimal track guidance for overlap welding and hem seams. With its automatic start and drive system, the foiler ETL welding machine makes welding tarpaulins, membranes and banners easy. It comes in two versions, 20mm / 0.8" mm or 30mm / 1.2" nozzles, with an additional material lifting device.
Highlights compact & strong
- 1700 W power rating
- available with 2 welding seam widths
- weld up to 7.5 m/min or 24.6 ft/min
- only 11kg
Application virtually unlimited
- advertising banner welding
- awning and wind blocker welding
- inflatable plastic fabric welding
- pool waterproofing
- protective cover welding
- tent tarpaulin welding
Technical Data
| Voltage | 230V |
| Frequency | 50/60 Hz |
| Power | 1700 W |
| Speed | 1 - 7.5 m/min |
| Temperature | 40 - 530 °C |
| Air Volume Adjustable | No |
| Welding Nozzle / Seam Width | 20 mm |
| LQS | No |
| Brushless Blower Motor | No |
| Length | 445 mm |
| Width | 280 mm |
| Height | 320 mm |
| Weight | 11 kg |
| Plug | CN, 3 poles, 16A |
| Power Cable Length | 2m |
| Approvals | CE |
| Protection Class | I |
| Country of Origin | P.R. China |
